Assembly
22
10.00 | PGN-plus-P | Assembly- and Operating Manual | en | 389753
Item Mounting PGN-plus-P
40 50 64 80 100 125
4 Bore for mounting screws M2.
5
M3 M4 M4 M5 M6
Mounting screw according
to standard
DIN EN ISO 4762
2 Centering sleeve Ø5 Ø6 Ø8 Ø8 Ø10 Ø12
Side C
5 Bore for mounting screws M2.
5
M3 M4 M5 M6 M8
Mounting screw according
to standard
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø5 Ø6 Ø8 Ø8 Ø10 Ø12
Item Mounting PGN-plus-P
160 200 240 300 380
Side A
1 Mounting screw M8 M10 M12 M16 M20
Max. depth of engagement
from locating surface [mm]
20.5 20 25.5 31 38
2 Centering sleeve Ø12 Ø14 Ø16 Ø22 Ø28
Side B
4 Bore for mounting screws M6 M8 M10 M12 M16
Mounting screw according
to standard
DIN EN ISO 4762
2 Centering sleeve Ø12 Ø12 Ø16 Ø22 Ø28
Side C
5 Bore for mounting screws M8 M10 M12 M16 M20
Mounting screw according
to standard
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø12 Ø14 Ø16 Ø22 Ø28
