Assembly
10.00 | PGN-plus-P | Assembly- and Operating Manual | en | 389753
43
5.4.13.1 Mounting the MMS 22-A-5V
Note: In order to mount the sensor MMS 22-A-5V, no additional
attachment kit is required.
Ø Assembling the sensor, Mounting analog MMS 22-A magnetic
switch [
}
39] .
Ø Connect the control unit output and adjust the sensor (see
assembly and operating manual of the sensor).
