*>>MAP 1<ENTER>
MAP 1<ENTER>MAP 1<ENTER>
MAP 1<ENTER>
Port 1 Database Assignments
Region Data Type # Records
GLOBAL --
LOCAL --
BUF --
D1 Unused
D2 B METER
D3 Unused
D4 Unused
D5 Unused
D6 Unused
D7 Unused
D8 Unused
A1 Unused
A2 Unused
A3 Unused
USER Unused
*>>
2. Verify that the relay meter data is parsed and stored in the SEL-2020 database. Determine
how data are stored within the data region with the MAP 1:METER command.
You should see a screen similar to the following:
*>>MAP 1:METER <ENTER>
MAP 1:METER <ENTER>MAP 1:METER <ENTER>
MAP 1:METER <ENTER>
Port 1, Data Region METER Map
Data Item Starting Address Type
_YEAR 2000h int
DAY_OF_YEAR 2001h int
TIME(ms) 2002h int[2]
IA(A) 2004h float[2]
IB(A) 2008h float[2]
IC(A) 200Ch float[2]
VA(V) 2010h float[2]
VB(V) 2014h float[2]
VC(V) 2018h float[2]
IAB(A) 201Ch float[2]
IBC(A) 2020h float[2]
ICA(A) 2024h float[2]
VAB(V) 2028h float[2]
VBC(V) 202Ch float[2]
VCA(V) 2030h float[2]
PA(MW) 2034h float
QA(MVAR) 2036h float
PB(MW) 2038h float
QB(MVAR) 203Ah float
PC(MW) 203Ch float
QC(MVAR) 203Eh float
P(MW) 2040h float
Q(MVAR) 2042h float
I0(A) 2044h float[2]
I1(A) 2048h float[2]
(continued on next page)
