SET THE SEL-2020, STEP-BY-STEP
Use SET A 8 to supply Port 8 with the timed trigger condition and the message to retrieve
contents of the A3 Data Region on Ports 1 through 7.
You should see the following screen:
*>>SET A 8<ENTER>
SET A 8<ENTER>SET A 8<ENTER>
SET A 8<ENTER>
Automatic message settings for Port 8
Auto-message Settings
How many auto-message sequences (0-12) MSG_CNT = 0 ? 1<ENTER>
1<ENTER>1<ENTER>
1<ENTER>
Item 1 trigger D1
ISSUE1 = NA
? T7:00 * MON + T7:00 * TUE +
T7:00 * MON + T7:00 * TUE + T7:00 * MON + T7:00 * TUE +
T7:00 * MON + T7:00 * TUE + T07:00 * WED + T07:00 * THU + T07:00 * FRI<ENTER>
T07:00 * WED + T07:00 * THU + T07:00 * FRI<ENTER>T07:00 * WED + T07:00 * THU + T07:00 * FRI<ENTER>
T07:00 * WED + T07:00 * THU + T07:00 * FRI<ENTER>
Item 1 message
MESG1 = ""
? \
\\
\IATDT3321890/
IATDT3321890/IATDT3321890/
IATDT3321890/\
\\
\F1:A3;CA/
F1:A3;CA/F1:A3;CA/
F1:A3;CA/\
\\
\F2:A3;CA/
F2:A3;CA/F2:A3;CA/
F2:A3;CA/\
\\
\F3:A3;CA/
F3:A3;CA/F3:A3;CA/
F3:A3;CA/\
\\
\F4:A3;CA/
F4:A3;CA/F4:A3;CA/
F4:A3;CA/\
\\
\F5:A3;CA/
F5:A3;CA/F5:A3;CA/
F5:A3;CA/\
\\
\<ENTER
<ENTER<ENTER
<ENTER
? \
\\
\F6:A3;CA/F7:A3;CA/<ENTER>
F6:A3;CA/F7:A3;CA/<ENTER>F6:A3;CA/F7:A3;CA/<ENTER>
F6:A3;CA/F7:A3;CA/<ENTER>
Archive Settings
Enable use of archive data items (Y/N) ARCH_EN = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Size of user-defined data space in registers USER = 0 ? <ENTER>
<ENTER> <ENTER>
<ENTER>
MSG_CNT = 1
ISSUE1 = T07:00:00.0 * MON + T07:00:00.0 * TUE + T07:00:00.0 *
WED + T07:00:00.0 * THU + T07:00:00.0 * FRI
MESG1 = "\IATDT3321890/\F01:A3;CA/\F02:A3;CA/\F03:A3;CA/\F04:A3;CA/\F05:A3;CA/\F06:A3;CA
/\F07:A3;CA/"
ARCH_EN = N
USER = 0
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 8 Settings Changed
*>>
Notes:

Set MESG_CNT=1 to add a new message trigger and message on Port 8.
Set ISSUE 1 as shown to trigger MESG1 every weekday morning, Monday through
Friday, at 7:00 a.m.
! Set MESG1 as shown to initiate a phone call to a remote computer, and send the
formatted long event report records stored in the A3 archive data region on Ports 1
through 7, clearing the archive region records as the records are read and sent. The \I
character string initiates the phone call using the given number. The records in each of
the A3 archive data regions on Ports 1 through 7 are read and cleared using the \F.../
string that outputs formatted data. The ;CA appended to the Port #:A3 address instructs
the SEL-2020 to read all records in the queue and clear them as they are read.

!
