Schweitzer Engineering Laboratories SEL-2020 - Appendix E: Planning Sheets

Date Code 20010518 Appendix E E-1
SEL-2020 Instruction Manual
APPENDIX E: PLANNING SHEETS
Date _________________________________
Approved by _________________________________
SEL-2020 Location _________________________________
Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7
Port 9
Alarm
External
IRIG-B
(Y/N)
Port 10 Port 11 Port 12 Port 13 Port 14 Port 15 Port 16 Port F
Port 8
Modem (Y/N)
SEL-2020 S/N _______________________
Connected
Device
Cable #
Connected
Device
Cable #
Optional I/O
Description Description
OUT1
OUT2
OUT3
OUT4
IN1
IN2
IN3
IN4
IN5
IN6
IN7
IN8
IN9
IN10
IN11
IN12
1N13
IN14
IN15
IN16
2020_20
Figure E.1: SEL-2020 Device Connection Plan
