Schweitzer Engineering Laboratories SEL-2020 - SET M - Math;Data Movement Settings

Date Code 20010518 Settings 6-35
SEL-2020 Instruction Manual
Table 6.15: SET L Logic Settings and Definitions
Setting Comment
SBR1-SBR16
Prompt. SBRn=.
Description. You enter a SEL
OGIC Control Equation definition for this set breaker
logic element.
CBR1-CBR16
Prompt. CBRn=.
Description. You enter a SEL
OGIC Control Equation definition for this clear
breaker logic element.
SRB1-SRB16
Prompt. SRBn=.
Description. You enter a SEL
OGIC Control Equation definition for this set remote
bit logic element.
CRB1-CRB16
Prompt. CRBn=.
Description. You enter a SEL
OGIC Control Equation definition for this clear
remote bit logic element.
SET M - MATH/DATA MOVEMENT SETTINGS
You use the SET M n command to create a macro that automatically copies specific data from
any designated SEL-2020 port database to the SEL-2020 port “n” database User region. This
permits you to concentrate selected data from one or more port databases into a single port
database User region for quick and easy data retrieval. You can also scale each selected data
item by multiplying or dividing by a scaling constant. The SET M n command permits you to
create up to 250 lines of equations and operations for each of the sixteen SEL-2020 port
databases.
This settings class is unique from all others. There are no settings labels and prompts. Instead,
you enter equations and operations as lines within the settings. Because of this, the edit control
keys and commands are slightly different. Table 6.16 lists the available editing keys and
commands.
Table 6.16: Editing Keys and Commands for SET M
Command Function
<ENTER>
Go to next line; if on empty line at end of settings, exit settings.
END<ENTER>
Exit settings.
<CTRL-X>
Abort settings (lose all changes).
^<ENTER>
Go back to previous line.
<<ENTER>
Go back to first line.
><ENTER>
Go to blank line following the last line.
n<ENTER>
Go to line n.
DELETE [n]<ENTER>
Delete the current line. If n is included, delete n lines, starting with the
current line.
INSERT<ENTER>
Insert a blank line at the current location; current line and all following
lines shift down one line.
