SET P Settings
When you issue the SET P command the SEL-2020 will prompt you for configuration and
communication parameters according to Table 6.3 for ports 1 through 16 and for port F. A
description of each prompt and a discussion about the appropriate responses to each prompt
follows these tables.
Table 6.3: SET P Prompts
“SET P n” Port Communications Setting Prompts for ports n = 1 through 16
SET P F
Prompts
DEVICE (U, S, O, P, M)
U(nused) S(EL IED) O(ther IED) P(rinter) M(aster)
CONFIG MODEM (Y/N)
PROTOCOL (L, S, M, D)
(Y/N) N(O) Y(ES)
L(MD) S(EL) M(odbus) D(NP)
MSTR ADDRESS FAST_OP MAP_TYPE ADDRESS
CD_CTS PREFIX START_ID CLASS
AUTO_ SETTLE SETTLE1 0 1-3
BAUD SETTLE2 16BIT
PROTOCOL (A/B) ADDRESS SO_TIMEOUT
A(SCII) B(inary) 1-16 DL_CONFIRM
0 1-15
DL_TIMEOUT
MIN_DELAY
MAX_DELAY
SETTLE1
SETTLE2
REPORT_ON
UNSOL_REP
N(O) Y(ES)
UNSOL_POW
REP_ADDR
NUM_EVENT
AGE_TX
CONFIRM_TO
PORTID PORTID PORTID PORTID PORTID
MODEM (Y/N) MODEM (Y/N)
N(O) Y(ES) N(O) Y(ES)
MSTR MSTR
CD_CTS CD_
CTS
BAUD BAUD BAUD BAUD BAUD
DATABIT DATABIT DATABIT DATABIT
STOPBIT STOPBIT STOPBIT STOPBIT
PARITY PARITY PARITY PARITY PARITY
RTS_CTS
(Y/N)
RTS_CTS (Y/N)* RTS_CTS
(Y/N)
RTS_CTS
(Y/N)*
RTS_CTS
(Y/N)*
XON/
XOFF
(Y/N)
XON/
XOFF
(Y/N)
XON/XOFF (Y/N) XON/XOFF (Y/N)
TIMEOUT TIMEOUT TIMEOUT TIMEOUT TIMEOUT
ECHO (Y/N)
AUTOHELP (Y/N) AUTOHELP (Y/N)
TERTIME1 TERTIME1
TERSTRING TERSTRING
TERTIME2 TERTIME2
Save changes (Y/N)
Y(ES) N(O)
Port n Settings Changed Settings aborted
*If CD_CTS=Y, RTS_CTS will not be available
Table 6.4 includes detailed information about the SET P settings.
