Date Code 20010518 “Job Done” Examples 4-1
SEL-2020 Instruction Manual
SECTION 4: “JOB DONE” EXAMPLES
INTRODUCTION
This section describes SEL-2020 operations and user interface with eight examples that include a
variety of common applications. In this manual, commands you type appear in bold/uppercase:
OTTER. Keys you press appear in bold/uppercase/brackets: <ENTER>. SEL-2020 output
screen images appear boxed and in the following format:
COMMUNICATIONS PROCESSOR - S/N 95012004 Date: 03/02/95 Time: 15:38:33
Explanatory notes: Explanatory notes associated with the SEL-2020 screen images are
provided below each screen image.
Each example assumes you have successfully performed the Initial Checkout described in
Section 1: Introduction, and you have configured the SEL-2020 hardware by placing jumpers
according to the instructions in the Installation subsection in Section 3: Installation. The
examples include an introduction to the problem or task, identification of the problem, overview
or definition of the solution, and the step-by-step procedure you should follow to accomplish the
solution with the SEL-2020.
