parameter to SHOWSET. (For example, use SHOWSET 5 to view all Port 5 settings.) Enter
parameters following the SHOWSET command in any order.
You cannot enter or modify settings with this command. Change settings with the SET
command.
STATUS (Access Level 1)
Use the STATUS command to inspect self-test status, the configuration of this unit, and the
status of each port. The SEL-2020 automatically sends the STATUS command response
message to Port F whenever the self-test software enters a warning or failure state. Add a repeat
count parameter to cause the STATUS command to repeat a given number of times. For
example, type STATUS 4 to view the status information four times.
The STATUS report format appears as follows:
*>>STATUS<ENTER>
*>>STATUS<ENTER>*>>STATUS<ENTER>
*>>STATUS<ENTER>
COMMUNICATIONS PROCESSOR - S/N 95012004 Date: 03/07/95 Time: 10:12:06
FID=SEL-2020-R100-V0-D950324
SELF-TESTS
RAM ROM EEPROM FLASH P.S. SET BATTERY
512 kb OK OK 2048 kb OK OK OK
IRIG-B Input: Present
I/O Board: Installed
Modem: Installed
Port Status Success Rate SET M Database Delays
1 Active 100% Running D2 D4 D5 D6 D7
2 Active 80% None D2 D3 D4 D5 D6 D7
3 Trans F 100% None
4 Active 100% Disabled D2 D3 D4 D5
5 Active 100% None
6 Active 66% None
7 Active 100% None D2 D3 D4 D5
8 Active None
9 Active None
10 Inactive None
11 Active None
12 Active None
13 Inactive None
14 Inactive None
15 Inactive None
16 Active 66% None
F Trans 3 None
*>>
Table 5.4 describes the STATUS report self-test and configuration fields.
The configuration information (RAM size, nonvolatile Flash memory size, IRIG-B input, I/O
board presence, and modem presence) reported in the status message is determined at system
power-up. A configuration item not reported as expected may indicate a problem in accessing
that item. If a failure occurs, the SEL-2020 will attempt to continue operating, but invalid data
may be reported.
