4-40 “Job Done” Examples - (Example 4) Date Code 20010518
SEL-2020 Instruction Manual
2. On Port 1, use the SET A command to enable archiving of data, and to define the issue
condition CMD1 to trigger event report collection (using the 20EVENT setting).
You should see the following screen:
*>>SET A 1<ENTER>
*>>SET A 1<ENTER>*>>SET A 1<ENTER>
*>>SET A 1<ENTER>
Automatic message settings for Port 1
Save Unsolicited Messages (Y/N) AUTOBUF = Y ? <ENTER>
<ENTER> <ENTER>
<ENTER>
Port Startup String
STARTUP ="ACC\nOTTER\n2AC\nTAIL\n"
? <ENTER>
<ENTER><ENTER>
<ENTER>
Send Operate command on Logic bit transition (Y/N) SEND_OPER=N ?<ENTER>
<ENTER><ENTER>
<ENTER>
Auto-message Settings
How many auto-message sequences (0-12) MSG_CNT = 2 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Item 1 trigger D1
ISSUE1 = T01:00:00.0
? <ENTER>
<ENTER><ENTER>
<ENTER>
Item 1 message
MESG1 = "DATE \RI;01:GLOBAL:MONTH//\RI;01:GLOBAL:DATE//\RI;01:GLOBAL:_YEAR/\n
? <ENTER>
<ENTER><ENTER>
<ENTER>
Item 1 response parsing method (0=IGNORE,
1=ASCII_INT, 2=ASCII_FLOAT, 3=CHAR_STRING, 4=INT_STRING)PARSE1 = 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Time delay to allow response to complete (OFF, ON) DELAY1 = ON ? <ENTER>
<ENTER><ENTER>
<ENTER>
Item 2 trigger D2
ISSUE2 = P00:00:01.0
? <ENTER>
<ENTER><ENTER>
<ENTER>
Item 2 message
MESG2 = 20METER
? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive Settings
Enable use of archive data items (Y/N) ARCH_EN = N ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Archive 1 trigger ARCH1
ISSUE1A = NA
? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive 2 trigger ARCH2
ISSUE2a = NA
? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive 3 trigger ARCH3
ISSUE3A = NA
? CMD1<ENTER>
CMD1<ENTER>CMD1<ENTER>
CMD1<ENTER>
Archive 3 message
MESG3A = ""
? 20
2020
20EVENT<ENTER>
EVENT<ENTER>EVENT<ENTER>
EVENT<ENTER>
Size of user-defined data space in registers USER = 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
(continued on next page)

!
