4-58 “Job Done” Examples - (Example 7) Date Code 20010518
SEL-2020 Instruction Manual
(SET A 1 continued from previous page)
Item 3 response parsing method (0=IGNORE,
1=ASCII_INT, 2 =ASCII_FLOAT, 3=CHAR_STRING, 4=INT_STRING)PARSE3 = 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Time delay to allow response to complete (OFF, ON) DELAY3 = ON ? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive Settings
Warning: Setting ARCH_EN = N will result in the loss of all Archive data and Archive settings for
this port.
Enable use of archive data items (Y/N) ARCH_EN = Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive 1 trigger ARCH1
ISSUE1A = NA
? <ENTER>
<ENTER> <ENTER>
<ENTER>
Archive 2 trigger ARCH2
ISSUE2A = NA
? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive 3 trigger ARCH3
ISSUE3A = 1:LOCAL:CMD1
? <ENTER>
<ENTER> <ENTER>
<ENTER>
Archive 3 message
MESG3A = 20EVENT
? <ENTER>
<ENTER> <ENTER>
<ENTER>
Size of user-defined data space in registers USER = 0 ? <ENTER>
<ENTER> <ENTER>
<ENTER>
AUTOBUF = Y
STARTUP ="ACC\nOTTER\n2AC\nTAIL\n"
SEND_OPER= N
MSG_CNT = 3
ISSUE1 = T01:00:00
MESG1 = "DATE \RI;01:GLOBAL:MONTH//\RI;01:GLOBAL:DATE//\RI;01:GLOBAL:_YEAR/\n"
PARSE1 = 0
DELAY1 = ON
ISSUE2 = P00:00:01.0
MESG2 = 20METER
ISSUE3 = 8:CMD1
MESG = “\RC;08:USER:0000h;23/”
PARSE3 = 0
DELAY3 = ON
Press RETURN to continue <ENTER>
<ENTER> <ENTER>
<ENTER>
ARCH_EN = Y
ISSUE1A = NA
ISSUE2A = NA
ISSUE3A = 1:CMD1
MESG3A = 20EVENT
USER = 0
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 1 Settings Changed
*>>
