4-68 “Job Done” Examples - (Example 9) Date Code 20010518
SEL-2020 Instruction Manual
Once you have confirmed that the relay is configured to support Fast Operate, use the SET A
command on Port 1 to enable direct operate control:
*>>SET A 1<ENTER>
SET A 1<ENTER>SET A 1<ENTER>
SET A 1<ENTER>
Automatic message settings for Port 1
Save Unsolicited Messages (Y/N) AUTOBUF = Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Port Startup String
STARTUP ="ACC\nOTTER\n2AC\nTAIL\n"
? <ENTER>
<ENTER><ENTER>
<ENTER>
Send Operate command on Logic bit transition (Y/N)SEND_OPER= N ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Auto-message Settings
How many auto-message sequences (0-12) MSG_CNT = 3 ? END<ENTER>
END<ENTER>END<ENTER>
END<ENTER>
AUTOBUF = Y
STARTUP ="ACC\nOTTER\n2AC\nTAIL\n"
SEND_OPER= Y
MSG_CNT = 3
ISSUE1 = T01:00:00.0
MESG1 = "DATE \RI;01:GLOBAL:MONTH//\RI;01:GLOBAL:DATE//\RI;01:GLOBAL:_YEAR/\n"
PARSE1 = 0
DELAY1 = ON
ISSUE2 = P00:00:01.0
MESG2 = 20METER
ISSUE3 = 8:CMD1
MESG3 = "\RC;08:USER:0000h;23/"
PARSE3 = 0
DELAY3 = ON
Press RETURN to continue<ENTER>
<ENTER><ENTER>
<ENTER>
ARCH_EN = Y
ISSUE1A = NA
ISSUE2A = NA
ISSUE3A = 1:CMD1
MESG3A = 20EVENT
USER = 0
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 1 Settings Changed
*>>
Notes:

Set SEND_OPER=Y to enable direct operate control via logic bits.
Repeat this process for Ports 2-7.
This operation will associate the port BR1 bit with the relay breaker. Whenever the SBR1 bit
asserts, the SEL-2020 will issue an OPEN command to the relay. Whenever the CBR1 bit

