Table 6.9: SET A Auto-Message Setting Prompts for PRINTER Device
STARTUP
MSG_CNT (0-12)
0 1 2-12
PRINT_ALL (Y/N)
Y(ES) N(O)
CLEAR_BUF (Y/N) ISSUE1 ISSUE2-12
MESG1 MESG2-12
USER
Save changes (Y/N)
Y(ES) N(O)
Port n Settings Changed Settings aborted
Table 6.10: SET A Auto-Message Settings Prompts for MASTER Device
PROTOCOL = SEL or LMD PROTOCOL = MODBUS or DNP
MSG_CNT (0-12) MSG_CNT (1-1)
0 1-12 0 1
ISSUE1-12 ISSUE1
MESG1-12 MESG1
ARCH_EN (Y/N) ARCH_EN(Y/N) only available
Y(ES) N(O) Y(ES) N(O)
with optional
ISSUE1A ISSUE1A nonvolatile
MESG1A MESG1A Flash memory
USER USER
Save changes (Y/N) Save Changes (Y/N)
Y(ES) N(O) Y(ES) N(O)
Port n Settings
changed
Settings aborted Port n Settings
changed
Settings aborted
