6-46 Settings Date Code 20010518
SEL-2020 Instruction Manual
SETTINGS SHEET - OTHER IED - SET P and SET A
Date
Approved by
SEL-2020 S/N
Port ( )
SET P
DEVICE U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) O
MODEM Modem control (Y/N)
MSTR Startup string (only if MODEM is Y)
CD_CTS Modem CD connected to CTS input (Y/N) (only if MODEM is Y)
AUTO_BAUD (Y/N)
PROTOCOL (A=ASCII , B=BINARY)
PORTID Port identification string
BAUD* (300,600,1200,2400,4800,9600,19200)
DATABIT Number data bits (7, 8)
STOPBIT Stop bits (1, 2)
PARITY (N, O, E, 1, 0)
RTS_CTS Enable RTS_CTS handshaking (Y/N)
XON_XOFF Enable XON_XOFF flow control (Y/N)
TIMEOUT Port timeout (0.0-30.0 minutes)
SET A
AUTOBUF Save Unsolicited messages (Y/N)
STARTUP Port Startup String
MSG_CNT How many auto-message sequences (0-12)
ISSUE1-12 Items 1-12 triggers D1-D12 = See Worksheet SET A
MESG1-12 Items 1-12 message See Worksheet SET A
PARSE1-8 Items 1-8 response parsing methods See Worksheet SET A
NUM1-8 Items 1-8 number of data items See Worksheet SET A
DELAY1-12 Items 1-12 time delay to allow response to complete (OFF,ON) See Worksheet SET A
CHECK1-8 Items 1-8 message validation See Worksheet SET A
ORDER1-8 Items 1-8 validation byte order See Worksheet SET A
START1-8 Items 1-8 validation start See Worksheet SET A
STOP1-8 Items 1-8 validation stop See Worksheet SET A
CHKPOS1-8 Items 1-8 validation position See Worksheet SET A
ACK1-8 Items 1-8 acknowledge string See Worksheet SET A
NACK1-8 Items 1-8 negative acknowledge string See Worksheet SET A
ARCH_EN Enable use of archive data items (Y/N)
ISSUE1A-3A Archive 1-3 trigger A1-A3 = See Worksheet SET A
MESG1A-3A Archive 1-3 messages See Worksheet SET A
PARSE1A-3A Archive 1-3 response parsing methods See Worksheet SET A
NUM1A-3A Archive 1-3 number of data items See Worksheet SET A
DELAY1A-3A Archive 1-3 time delay to allow response to complete (OFF,ON) See Worksheet SET A
CHECK1A-3A Archive 1-3 message validation See Worksheet SET A
ORDER1A-3A Archive 1-3 validation byte order See Worksheet SET A
START1A-3A Archive 1-3 validation start See Worksheet SET A
