Table 9.4: Global Element Definitions
Element Definition
SUN Sunday Flag
MON Monday Flag
TUE Tuesday Flag
WED Wednesday Flag
THU Thursday Flag
FRI Friday Flag
SAT Saturday Flag
IRIG IRIG-B Input Present Flag is set when IRIG-B input is sensed.
V Intermediate Element V
W Intermediate Element W
X Intermediate Element Y
XT X Element Timer Output
Y Intermediate Element Y
YT Y Element Timer Output
Z Intermediate Element Z
ZT Z Element Timer Output
R1 Remote Bit 1
R2 Remote Bit 2
. .
. .
. .
R8 Remote Bit 8
PINAC A port is in a Power-Up Inactive State
PCF A port is in a Power-Up Configuration Failure State
INAC A port is in an Inactive State
SDLY A SELOGIC Control Equation automatic message operation has been missed on a
port.
* Unused
SALARM Settings Change Alarm
IN8 Input Eight Element
IN7 Input Seven Element
. .
. .
. .
IN1 Input One Element
IN16 Input Sixteen Element
IN15 Input Fifteen Element
. .
. .
. .
IN9 Input Nine Element
OUT1 Output One Element
OUT2 Output Two Element
OUT3 Output Three Element
OUT4 Output Four Element
* Unused
Available with Optional I/O Board
