G-10 Appendix G Date Code 20010518
SEL-2020 Instruction Manual
Connect the IRIG-B terminal at the Y end to the relay’s AUX input port. Connect the single
connector end of the cable to Port 2 on the SEL-2020.
2. Connect a Modbus master device to an SEL-2020 Modbus port; this example uses Port 16.
3. Change the SEL-2020 access level to Access Level 2 on the SEL-2020 and issue the
command SET P 16 to configure Port 16. The SEL-2020 will prompt for the type of device
connected to the port. Enter M for Master, enter M a second time for Modbus protocol.
Select the default floating-point map and set the start ID to 0. Assign an address to Port 2
and enter OFF for other port addresses. See the following example:
*>>SET P 16<ENTER>
SET P 16<ENTER>SET P 16<ENTER>
SET P 16<ENTER>
Port communications settings for Port 16
Device Type (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) DEVICE = S ? M<ENTER>
M<ENTER>M<ENTER>
M<ENTER>
Communications Type (S=SEL, L=LMD, M=MODBUS) PROTOCOL= S ? M<ENTER>
M<ENTER>M<ENTER>
M<ENTER>
Modbus Map Type (F=Float, I=Integer) MAP_TYPE= F ? <ENTER>
<ENTER><ENTER>
<ENTER>
Starting Code for ID List (0-255) START_ID= 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Transmission delay from RTS assertion (0-30000 milliseconds) SETTLE1=0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Post-transmit RTS de-assertion delay (0-30000 milliseconds) SETTLE2=0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Address of Port 1 (1-247) ADDRESS1= OFF ? <ENTER>
<ENTER><ENTER>
<ENTER>
Address of Port 2 (1-247) ADDRESS2= OFF ? 6<ENTER>
6<ENTER>6<ENTER>
6<ENTER>
Address of Port 3 (1-247) ADDRESS3= OFF ? END<ENTER>
END<ENTER>END<ENTER>
END<ENTER>
PORT:16
DEVICE = M
PROTOCOL= M
MAP_TYPE= F
START_ID= 0
SETTLE1 = 0
SETTLE2 = 0
ADDRESS1= OFF ADDRESS2= 6 ADDRESS3= OFF ADDRESS4= OFF
ADDRESS5= OFF ADDRESS6= OFF ADDRESS7= OFF ADDRESS8= OFF
ADDRESS9= OFF ADDRESS10= OFF ADDRESS11= OFF ADDRESS12= OFF
ADDRESS13= OFF ADDRESS14= OFF ADDRESS15= OFF ADDRESS16= OFF
PORTID =""
BAUD = 9600
PARITY = N
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 16 Settings Changed
*>>
4. Issue the command SET P 2 to configure Port 2. The SEL-2020 will prompt for the type of
device connected to the port. Enter S for SEL IED, enter Y to auto-configure the port, and
press <ENTER> to confirm the configuration prompts. The SEL-2020 will establish
communication with the relay, relay ID, and communication baud rate and determine if the
relay is capable of Fast Meter. Enter Y to save port configuration changes at the final
prompt.
