Date Code 20010518 Appendix G G-13

SEL-2020 Instruction Manual

(continued from previous page)

Address of Port 1 (1-247) ADDRESS1= OFF ? <ENTER>

<ENTER>

Address of Port 2 (1-247) ADDRESS2= OFF ? <ENTER>

<ENTER>

Address of Port 3 (1-247) ADDRESS3= OFF ? 15<ENTER>

15<ENTER>15<ENTER>

15<ENTER>

Address of Port 4 (1-247) ADDRESS4= OFF ? 16<ENTER>

16<ENTER>16<ENTER>

16<ENTER>

Address of Port 5 (1-247) ADDRESS5= OFF ? <ENTER>

<ENTER>

Address of Port 6 (1-247) ADDRESS6= OFF ? <ENTER>

<ENTER>

Address of Port 7 (1-247) ADDRESS7= OFF ? <ENTER>

<ENTER>

Address of Port 8 (1-247) ADDRESS8= OFF ? <ENTER>

<ENTER>

Address of Port 9 (1-247) ADDRESS9= OFF ? <ENTER>

<ENTER>

Address of Port 10 (1-247) ADDRESS10= OFF ? <ENTER>

<ENTER>

Address of Port 11 (1-247) ADDRESS11= OFF ? <ENTER>

<ENTER>

Address of Port 12 (1-247) ADDRESS12= OFF ? <ENTER>

<ENTER>

Address of Port 13 (1-247) ADDRESS13= OFF ? <ENTER>

<ENTER>

Address of Port 14 (1-247) ADDRESS14= OFF ? <ENTER>

<ENTER>

Address of Port 15 (1-247) ADDRESS15= OFF ? <ENTER>

<ENTER>

Address of Port 16 (1-247) ADDRESS16= OFF ? 17<ENTER>

<ENTER>

Port Identification String

PORTID =""

? Modbus Port<ENTER>

Modbus Port<ENTER>Modbus Port<ENTER>

Modbus Port<ENTER>

Communications Settings

Baud Rate (300, 600, 1200, 2400, 4800, 9600,

19200, 38400) BAUD = 9600 ? <ENTER>

<ENTER>

Parity (N,O,E) PARITY = N ? <ENTER>

<ENTER>

PORT:16

DEVICE = M

PROTOCOL= M

MAP_TYPE= F

START_ID= 0

SETTLE1 = 0

SETTLE2 = 0

ADDRESS1= OFF ADDRESS2= OFF ADDRESS3= 15 ADDRESS4= 16

ADDRESS5= OFF ADDRESS6= OFF ADDRESS7= OFF ADDRESS8= OFF

ADDRESS9= OFF ADDRESS10= OFF ADDRESS11= OFF ADDRESS12= OFF

ADDRESS13= OFF ADDRESS14= OFF ADDRESS15= OFF ADDRESS16= 17

PORTID ="Modbus Port"

BAUD = 9600

PARITY = N

Save changes (Y/N) ? Y<ENTER>

<ENTER>

Port 16 Settings Changed

*>>
