Date Code 20010518 Appendix G G-15
SEL-2020 Instruction Manual
4. Set-up the Port 16 user region to hold the currents and voltages of interest using the
command SET M 16:
*>>SET M 16<ENTER>
SET M 16<ENTER>SET M 16<ENTER>
SET M 16<ENTER>
Mathematical/move equation settings for Port 16
1
? 0=3:METER:IA<ENTER>
0=3:METER:IA<ENTER>0=3:METER:IA<ENTER>
0=3:METER:IA<ENTER>
2
? 1=3:METER:IB<ENTER>
1=3:METER:IB<ENTER>1=3:METER:IB<ENTER>
1=3:METER:IB<ENTER>
3
? 2=3:METER:IC<ENTER>
2=3:METER:IC<ENTER>2=3:METER:IC<ENTER>
2=3:METER:IC<ENTER>
4
? 3=3:METER:VA<ENTER>
3=3:METER:VA<ENTER>3=3:METER:VA<ENTER>
3=3:METER:VA<ENTER>
5
? 4=3:METER:VB<ENTER>
4=3:METER:VB<ENTER>4=3:METER:VB<ENTER>
4=3:METER:VB<ENTER>
6
? 5=3:METER:VC<ENTER>
? 5=3:METER:VC<ENTER>? 5=3:METER:VC<ENTER>
? 5=3:METER:VC<ENTER>
7
? 6=4:METER:IAX<ENTER>
6=4:METER:IAX<ENTER>6=4:METER:IAX<ENTER>
6=4:METER:IAX<ENTER>
8
? 7=4:METER:IBX<
7=4:METER:IBX<7=4:METER:IBX<
7=4:METER:IBX<ENTER>
ENTER>ENTER>
ENTER>
9
? 8=4:METER:ICX<ENTER>
8=4:METER:ICX<ENTER>8=4:METER:ICX<ENTER>
8=4:METER:ICX<ENTER>
10
? 9=4:METER:IAY<ENTER>
9=4:METER:IAY<ENTER>9=4:METER:IAY<ENTER>
9=4:METER:IAY<ENTER>
11
? 10=4:METER:IBY<ENTER>
10=4:METER:IBY<ENTER>10=4:METER:IBY<ENTER>
10=4:METER:IBY<ENTER>
12
? 11=4:METER:ICY<ENTER>
11=4:METER:ICY<ENTER>11=4:METER:ICY<ENTER>
11=4:METER:ICY<ENTER>
13
? <ENTER>
<ENTER> <ENTER>
<ENTER>
1 000h = 3:METER:IA(A)
2 001h = 3:METER:IB(A)
3 002h = 3:METER:IC(A)
4 003h = 3:METER:VA(V)
5 004h = 3:METER:VB(V)
6 005h = 3:METER:VC(V)
7 006h = 4:METER:IAX(A)
8 007h = 4:METER:IBX(A)
9 008h = 4:METER:ICX(A)
10 009h = 4:METER:IAY(A)
11 00Ah = 4:METER:IBY(A)
12 00Bh = 4:METER:ICY(A)
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
USER database region too small: Current size = 0 Size needed = 12
Attempting to allocate larger USER region... Done.
Port 16 Settings Changed
*>>
5. The SEL-2020 is now collecting meter data from the two relays. The items of interest are
being copied to the Port 16 user region every half second. You can now access this data via
Modbus. For this example, we will read the data using function code 03 from address
F800h. (Section 9: Database shows that the User region starts at address F800h.) The data
could also be read using function code 04 from address 2400 (0960h). To read the data, send
the following message:
