Date Code 20010518 Appendix I I-7
SEL-2020 Instruction Manual
OBJECT REQUEST
(supported)
RESPONSE
(may generate)
Obj Var
*def
Description
Func
Codes
(dec)
Qual
Codes
(hex)
Func
Codes
(dec)
Qual
Codes
(hex)
31 4 16-Bit Frozen Analog Input with Time of Freeze
31 5 32-Bit Frozen Analog Input without Flag
31 6 16-Bit Frozen Analog Input without Flag
32 0 Analog Change Event - All Variations 1 6,7,8
32 1* 32-Bit Analog Change Event without Time 1 6,7,8 129,130 17,28
32 2* 16-Bit Analog Change Event without Time 1 6,7,8 129,130 17,28
32 3 32-Bit Analog Change Event with Time 1 6,7,8 129 17,28
32 4 16-Bit Analog Change Event with Time 1 6,7,8 129 17,28
33 0 Frozen Analog Event - All Variations
33 1 32-Bit Frozen Analog Event without Time
33 2 16-Bit Frozen Analog Event without Time
33 3 32-Bit Frozen Analog Event with Time
33 4 16-Bit Frozen Analog Event with Time
40 0 Analog Output Status - All Variations 1 0,1,6
40 1 32-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
40 2* 16-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
41 0 Analog Output Block - All Variations
41 1 32-Bit Analog Output Block
41 2 16-Bit Analog Output Block 3,4,5,6 17,28 129
echo of
request
50 0 Time and Date - All Variations
50 1 Time and Date 2
07, quan-
tity=1
1
07, quan-
tity=1
129
07, quan-
tity=1
50 2 Time and Date with Interval
51 0 Time and Date CTO - All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO
07, quan-
tity=1
52 0 Time Delay - All Variations
52 1 Time Delay Coarse
52 2 Time Delay Fine 129
07, quan-
tity=1
60 0
60 1 Class 0 Data 1 06
60 2 Class 1 Data 1,20,21 06,07,08
60 3 Class 2 Data 1,20,21 06,07,08
60 4 Class 3 Data 1,20,21 06,07,08
70 1 File Identifier
