I-10 Appendix I Date Code 20010518
SEL-2020 Instruction Manual
Table I.4: Binary Output Objects
Index
Range Applicable Port Covered Bits
0-7 N/A R1-R8
8-83 Selected by Analog Object
Index 0
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
84-159 Port 1
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
160-235 Port 2
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
236-311 Port 3
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
312-387 Port 4
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
388-463 Port 5
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
464-539 Port 6
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
540-615 Port 7
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
616-691 Port 8
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
692-767 Port 9
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
768-843 Port 10
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
844-919 Port 11
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
920-995 Port 12
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
996-1071 Port 13
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
1072-1147 Port 14
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
1148-1223 Port 15
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
1224-1299 Port 16
CMD1-CMD8, SBO1-SBO4, SBR1-SBR16,
SRB1-SRB16, CBR1-CBR16, CRB1-CRB16
