2-18 General Description Date Code 20010518
SEL-2020 Instruction Manual
*>>WHO<ENTER>
WHO<ENTER>WHO<ENTER>
WHO<ENTER>
Date: 03/06/95 Time: 09:05:20
FID=SEL-2020-R115-V0-D961020
Port # Device Protocol Parameters Identification
1 SEL-151 SEL 9600,8,2,N Example 21.6 kV Feeder - S/N 93245011
2 SEL IED SEL 9600,8,2,N
3 SEL IED SEL 9600,8,2,N
4 SEL IED SEL 9600,8,2,N
5 SEL IED SEL 9600,8,2,N
6 SEL IED SEL 9600,8,2,N
7 SEL IED SEL 9600,8,2,N
8 Master SEL 9600,8,2,N
9 Printer Ascii 9600,8,2,N
10 SEL IED SEL 9600,8,2,N
11 SEL IED SEL 9600,8,2,N
12 SEL IED SEL 9600,8,2,N
13 SEL IED SEL 9600,8,2,N
14 SEL IED SEL 9600,8,2,N
15 SEL IED SEL 9600,8,2,N
16 SEL IED SEL 9600,8,2,N
F* Master SEL 2400,8,2,N
*>>
The displayed response to the WHO command also identifies that Master port currently in
use by an '*' next to its port number: Port F in the current example.
b) Verify the location and type of data being collected on Port 1 of the SEL-2020 by
issuing the command string MAP 1. The SEL-2020 responds with a database map of
the Port 1 data regions. This map shows that meter data are being collected in Port 1
region D1, which is associated with Port 1 Message 1. The B METER indicates that the
SEL-2020 is receiving binary, or Fast Meter, data from the SEL-251 Relay. If the
SEL-251 Relay did not have Fast Meter capability, there would be an “A” next to
METER, indicating that the data are transferred in ASCII format.
*>>MAP 1<ENTER>
MAP 1<ENTER>MAP 1<ENTER>
MAP 1<ENTER>
Port 1 Database Assignments
Region Data Type # Records
GLOBAL --
LOCAL --
BUF --
D1 B METER
D2 Unused
D3 Unused
D4 Unused
D5 Unused
D6 Unused
D7 Unused
D8 Unused
A1 Unused
A2 Unused
A3 Unused
USER Unused
*>>
You can refer to the specific data region by the region name, D1, or the data name, METER.
