2-20 General Description Date Code 20010518
SEL-2020 Instruction Manual
*>>VIEW 1:METER <ENTER>
VIEW 1:METER <ENTER>VIEW 1:METER <ENTER>
VIEW 1:METER <ENTER>
Port 1, Data Region METER Data
_YEAR = 1995 DAY_OF_YEAR = 1 (01/01) TIME = 01:59:37.859
IA(A) = 2374.623, 102.078 IB(A) = 2353.747, -17.810
IC(A) = 2369.258, -137.949 VA(V) = 11278.516, 103.606
VB(V) = 11289.020, -16.545 VC(V) = 11270.235, -136.424
IAB(A) = 4092.593, 131.987 IBC(A) = 4093.101, 12.229
ICA(A) = 4107.771, -107.898 VAB(V) = 19558.934, 133.546
VBC(V) = 19524.914, 13.488 VCA(V) = 19524.873, -106.397
PA(MW) = 26.773 QA(MVAR) = 0.714 PB(MW) = 26.565
QB(MVAR) = 0.587 PC(MW) = 26.693 QC(MVAR) = 0.711
P(MW) = 80.030 Q(MVAR) = 2.012 I0(A) = 7.170, 135.000
I1(A) = 2365.875, 102.106 I2(A) = 5.750, 40.418
V0(V) = 7.299, -80.537 V1(V) = 11279.251, 103.546
V2(V) = 13.106, 163.608
*>>
Note that all current and voltages are reported in primary system quantities.
e) Check the communication and data retrieval performance by issuing the SEL-2020
STATUS command. The SEL-2020 responds with SEL-2020 general information,
optional equipment information, and communication performance, including a listing of
ports with their respective communication status, communication success rate, and data-
base delays. In this example, the SEL-251 Relay is connected to the SEL-2020’s Port 1,
which is shown with active status and 100% communication success rate. If the relay is
disconnected or turned off, the status changes to inactive. If database delays were
encountered on this port, the specific region, or regions, affected would be listed under
database delays. If these delays were a problem, you could adjust the data collection
period or times to prevent overrunning data that can cause database delays.
