4-12 “Job Done” Examples - (Example 1) Date Code 20010518
SEL-2020 Instruction Manual
(SET P 8 continued from previous page)
Echo received characters (Y/N) ECHO = Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Automatic help messages enabled (Y/N) AUTO_HELP= Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Transparent Communications Termination Sequence
First delay time (0-600 seconds) TERTIME1= 1 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Termination string
TERSTRING="\004"
? <ENTER>
<ENTER><ENTER>
<ENTER>
Second delay time (0-600 seconds) TERTIME2= OFF ? <ENTER>
<ENTER><ENTER>
<ENTER>
PORT:8
DEVICE = M
PROTOCOL= S
FAST_OP = Y
PORTID ="MODEM"
MSTR ="ATX0E0&D0%E1S0=4"
BAUD = 38400
DATABIT = 8 STOPBIT = 2 PARITY = N
RTS_CTS = N XON_XOFF= Y
TIMEOUT = 30.0 ECHO = Y
AUTO_HELP= Y
TERTIME1= 1
TERSTRING="\004"
TERTIME2= OFF
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 8 Settings Changed
*>>
Note:
#
Type Y<ENTER> to accept port setting changes.
#
