Schweitzer Engineering Laboratories SEL-251 - Example Event Report 1

Date Code 970103 Event Reporting 4-7
SEL-251, -2, -3 Instruction Manual
Example Event Report 1
Example 21.6 kV distribution feeder Date: 4/1/93 Time: 01:07:35.862
FID=SEL-151-R407-V656rp1rq-D921229-E2
Currents Voltages P Q N I Out In
(A pri) (V pri)
555T 55 555 D 7B T13A 135
IR IA IB IC VA VB VC 100C 10 100 E 9K &&&L &&&
LHI LH M R C24R 246
-1 310 -171 -141 12377 -4872 -7505 .... .. ... . R. .... 13B
3 16 262 -276 -1520 11479 -9959 .... .. ... . R. .... 13B
1 -310 171 141 -12377 4872 7505 .... .. ... . R. .... 13B
-3 -16 -262 276 1520 -11479 9959 .... .. ... . R. .... 13B
Event : TRIG Location : Shot: 0 Targets:
Currents: (ABCQN; amps, primary) 310 313 310 2 3
One cycle of data
Event Summary
