Schwing CPC III - Status LCD Display; Joystick Configuration - Example

15
Operation
CPC III Manual
Status LCD Display
The Status LCD Display gives the operator feedback
on various functions and warnings through the display
window.
Joystick Conguration - Example
See original operation manual for proper conguration
ITEM
1
2
3
4
5
6
FUNCTION
Battery Level
Machine Status:
- RPMs
- Hydraulic Oil Temperature
- Concrete Pump Pressure (optional)
- Strokes per minute (optional)
Signal Strength Status
Error Messages
Green light: E-Stop is clear and hopper grate
is closed
Alarm horn is activated. It will beep 5 times
every 30 seconds until the error is
acknowledged.
LED
A
B
C
D
E
FUNCTION
E-Stop Cleared / Hopper grate closed
Not Used
E-Stop Cleared / Switch engaged (Soft Stop)
Not Used
Alarm horn active. Will turn off when alarm is
acknowledged
11
3
2
4
5
6
Water Tank Low
Left Joystick
#2 Boom Up #2 Boom Down
#2 BoomNot Used
Tip Retract
Tip Retract
Plus
Boom #3
Tip Retract
Plus
Boom #3
Boom #3
Plus
Tip Extend
Boom #3
Plus
Tip Extend
Boom #3
Extend
Boom #3
Retract
Tip Extend
Right Joystick
#1 Down
#1 Down
Plus
Slewing CCW
#1 Down
Plus
Slewing CW
#1 Up
Plus
Slewing CCW
#1 Up
Plus
Slewing CW
Slewing Counter-
Clockwise (CCW)
Slewing
Clockwise (CW)
#1 Up
