Schwing CPC III - 98458772-Assy CPC3 Control Panel(1 of 2)

29CPC III Manual
Item Qty Description Part #Item Qty Description Part #
0010 1 Control panel CPC3 Bracket 98457553
0050 1 Control panel CPC3 Front Cover 98457517
0051 4 Parts Plastic-Head Thumb Screws M6 10mm 98465073
0052 1 Decal – CPC III Main Panel 98465796
0060 1 Harness CPC3 MAIN 98457837
0070 2 Screw ISO 4017 M 6 x 16-8.8-VZD 10001762
0071 2 Screw retainer SKM 6-GT320 10134153
0090 16 Screw DIN 84 M 3 x 10-4.8 30311675
0091 16 Washer DIN 125 A 3.2-140HV 30311676
0092 16 Nut ISO 4032 M 3-8-VZD 10001229
0120 1 Connector M12 Bulkhead Passthrough 98449766
0130 1 Parts Controller Safety, PLC, CR7132 98391422
0131 4 Screw DIN 912 M 4 x 10-8.8 30359685
0150 1 Module PDM VEC CPC3 98465074
0151 1 Decal – CPC III Fuse Designation 98465798
0152 4 Screw ISO 4017 M 6 x 16-8.8-VZD 10001762
0153 4 Washer DIN 125 B 6.4-140HV-VZD 10011106
0190 1 Display 2.8" CAN 98395784
0191 1 Display bezel SP electronic trailer 98359938
0210 1 Switch Ignition Keyed-601 2Pos 98449359
0220 2 Sealant dielectric grease 98424548
0230 1 Assy Switch Toggle 4PDT On-On Maintain 98463187
98458772-Assy CPC3 Control Panel(1 of 2)
