Schwing CPC III - Page 42

DATE
SHEET NUMBER
REV.
SIZE
DRAWING NUMBER
B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A
A
B
B
C
C
Schematic CPC3
01
98455320
10 of 18
6/10/20
OUTPUTS EX00 - EX07 ARE POWERED BY VBB1
REFERENCE ONLY
SP18
JFC
G d
PFC
G
d
P17/C-5
PLCEX
18 17 16 15 14 13 12 11
PBC
D
C
S
R
Y
Z
V
P17/A-5
JBC
D C S R Y Z V
STROKE
LIMITER
TELESCOPE
EXTEND
BOOM 1 DOWNBOOM 1 UPTELESCOPE
RETRACT
PLC - 98391422
EX18 - OUT00
STROKE LIMITER
EX17 - OUT01
TELESCOPE EXTEND
EX16 - OUT02
TELESCOPE RETRACT
EX15 - OUT03
BOOM 1 UP
EX14 - OUT04
BOOM 1 DOWN
EX13 - OUT05 EX12 - OUT06 EX11 - OUT07
PLCEX:18-PFC:G
WH 0.8mm²
PLCEX:14-PBC:D
WH 0.8mm²
PLCEX:15-PBC:C
WH 0.8mm²
PLCEX:16-PBC:S
WH 0.8mm²
PLCEX:17-PBC:R
WH 0.8mm²
PDM3:H-PFC:d
GY 0.8mm²
P3/C-6
PDM10:H-PBC:V
GY 0.8mm²
P3/C-2
PDM11:A-PBC:Y
GY 0.8mm²
P3/C-2
PDM11:B-PBC:Z
GY 0.8mm²
P3/C-2
