Schwing CPC III - Page 45

DATE
SHEET NUMBER
REV.
SIZE
DRAWING NUMBER
B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A
A
B
B
C
C
Schematic CPC3
01
98455320
13 of 18
6/10/20
OUTPUTS EX24 - EX31 ARE POWERED BY VBB4
REFERENCE ONLY98465557
WORK LIGHTS
REFERENCE ONLY
REFERENCE ONLY
98457028
JIOC
K I A
SP26
JMC
D
PMC
D
P13/A-6
JMC
F
PMC
F
P13/B-6
PRC
V
P17/C-8
PIOE
9 8
P16/C-3
PLCEX
42 43 44 45 46 47 48 49
JIOE
9 8
JRC
V
SP16
PIOC
K
I
A
P7/B-8
AGITATOR
FWD
AGITATOR REV
PLC - 98391422
EX42 - OUT24
TOWER HORN
EX43 - OUT25 EX44 - OUT26
WORK LIGHTS BOOM
EX45 - OUT27
AGITATOR FWD
EX46 - OUT28
AGITATOR REV
EX47 - OUT29
VIBRATOR
EX48 - OUT30
OIL COOLER
EX49 - OUT31
BOOM HORN
PDM1:A-PLCEX:42
WH 0.8mm²
P3/A-8
PLCEX:45-JIOE:9
WH 0.8mm²
PLCEX:46-JIOE:8
WH 0.8mm²
PDM9:G-PLCEX:47
WH 0.8mm²
P3/A-5
PLCEX:48-SP16
WH 0.8mm²
PDM4:A-PLCEX:49
WH 0.8mm²
P3/A-7
PDM12:E-SP16
WH 0.8mm²
P3/A-3
PIOE:9-PIOC:K
WH 0.8mm²
PIOE:8-PIOC:I
WH 0.8mm²
PIOC:A-SP23
GY 0.8mm²
P16/B-3
PLCEX:44-PRC:V
WH 0.8mm²
D:F
WH 0.8mm²
PDP2:1-SP16
WH 0.8mm²
P8/B-8
