OM-610-1002-1 Operator’s Manual Rev 37
PDS-2010 SECTION 4 INSTALLATION page 9
SECTION 4 INSTALLATION
4.1 PDS 2010 INSTALLATION REQUIREMENTS
Refer to the correct Electrical Schematic for your unit. The PDS 2010 series lab coater is equipped with a
grounding type power plug, which MUST be connected to a grounded outlet to prevent electrical shock.
The PDS 2010 is provided to international users with an unterminated power cord so that the appropriate
power plug may be attached. Select the plug that is rated for the current and supply circuit voltage that is
available.
NOTE: The supply circuit must be overcurrent protected at a value not exceeding 20 amps.
The customer is required to place the equipment in the work area, reassemble and level the equipment,
and provide all required on-site services, labor, and materials necessary to install the services to the
equipment.
The following checklist is provided for the installation of the equipment. Complete the installation
checklist while installing the equipment.
If an SCS Installation/Start-up service call is scheduled, the customer’s installation must be completed
before the arrival of the SCS service technician. The customer is requested to give a minimum one-week
notice for the scheduled service calls.
4.2 ON SITE SERVICES PROVIDED BY THE CUSTOMER
Standard PDS 2010 Electrical Service 110 Volts AC, 20 Amps, 1∅, 60 Hz
220 Volts AC, 12 Amps, 1∅, 50 Hz
Standard Mechanical Chiller Electrical Service 110 Volts AC, 12 Amps, 1∅, 60 Hz
220 Volts AC, 6 Amps, 1∅, 50 Hz
4.3 SHIPPING DAMAGE
Carefully inspect the PDS 2010 for damage at the time of delivery. Note any damage on the bill
of lading. Notify the local agent of the carrier and Specialty Coating Systems immediately.
The PDS 2010 will have to be made available for inspection by an examining agent for the
carrier. Do not return the PDS 2010 for repairs unless shipping instructions and authorization are
received. Unless these procedures are followed, the carrier cannot accept responsibility.
If a claim must be filed to pay for damages to the equipment during transit, it is the responsibility
of the customer to file the claim.
4.4 UNPACKING
Remove any packing, straps, or other such restraints used to protect the equipment in shipment.
