OM-610-1002-1 Operator’s Manual Rev 37
PDS-2010 SECTION 7 COMPONENT LOCATION page 59
SECTION 7 COMPONENT LOCATION & PART NUMBERS
7.1 COMPONENT LOCATION-Standard Machine
The locations of system components are shown on the following pages. Sub-system assembly drawings,
AD-xxx-xxxx-x, are proceeded by a Bill of Material, SA-xxx-xxxx-x. Components may be identified by cross
referencing the number inside the balloon (BOM Sequence No. on the Bill of Material) on the drawing with the
SCS Part Number on the Bill of Material. Parts must be ordered using the SCS Part Number, not the balloon
number.
The following Assemblies are included-
ITEM
ASSEMBLY
FACILITIES DRAWING FD-610-1007-1
ASSEMBLY, 120 Volt 60 Hz. AD-610-1010-1
ASSEMBLY, 220 Volt 50 Hz. AD-610-1011-1
ASSEMBLY, 200 Volt, w/o Pump AD-610-1065-1
FRAME, Basic Assembly AD-286-1041-1
ELECT CTRL Panel Assembly AD-610-1001-4
LOAD DOOR Assembly AD-215-1007-1
VAPORIZER/PYROLYSIS Heater Assembly AD-374-1029-2
FIXTURE Rotation Assembly AD-241-1007-1
7.2 COMPONENT LOCATION-Options
LN
2
CHILLER Assembly AD-157-1019-1
LN
2
SENSOR Assembly AD-724-1097-1
Standard FIXTURE Assembly AD-241-1008-1
Standard CHAMBER D50016
CHAMBER, w/ Viewport & Lid AD-088-1031-1
CHAMBER, Reduced Dome FP-088-1081-1
TUMBLE Kit AD-285-1161-1
TUMBLE ADAPTER KIT AD-285-1055-1
FIXTURE, 2010 @3” CHAMBER AD-241-1185-1
TUMBLER SCREEN BASKET AD-684-1005-1
