Rev 37 Operator’s Manual OM-610-1002-1
page 46 SECTION 6 MAINTENANCE PDS-2010
6.4.3 To Enter the Setup Mode:
1. Depress and hold the Function key and depress the Raise key to access Select Mode. The upper
display will read OPtr and display will read SLCt.
2. Press the Raise key once. The upper display will show SetP.
3. Press the Function key once. The lower display will show Uloc.
4. Use the Raise key to increment the
PV value until the upper display shows the proper Unlock code
(the default code is 10), and then depress the Function key. The
MAN light will come on and display
the first parameter in the Setup Mode menu.
5. Use the Function key to scroll through the menu. Use the Raise and Lower keys to increment and
decrement the values of each parameter.
6.4.4 To exit the Setup Mode:
1. Depress and hold the Function key and depress the Raise key to return to Select Mode. This will also
cause the
MAN light to go off.
2. Use the Lower key to select Optr and depress the Function key to return to Operator Mode.
