SCS LABCOTER 2 - Factory Settings

OM-610-1002-1 Operator’s Manual Rev 37
PDS-2010 SECTION 6 MAINTENANCE page 47
6.4.5 Factory Settings
Configuration Mode (with hardware definition code
1
)
Parameter Furnace Chamber Gauge Vaporizer Vacuum
inPt
JC JC JC 0_10
ruL
761 761 761 1112
rLL
0 0 0 -4
dPoS
--- --- --- 0
CtyP
SnGL SnGL SnGL SnGL
CtrL
rEv rEv rEv rEv
ALA 1
bAnd bAnd P_Hi P_Lo
bAL 1
--- --- --- ---
PhA 1*
--- --- --- ---
PLA 1*
--- --- --- ---
AHY 1*
1 1 1 1
ALA 2*
nonE nonE P_Hi nonE
PhA 2*
--- --- --- ---
AHY 2*
--- --- 1 ---
LAEn
diSA diSA diSA diSA
Inh i
nonE nonE nonE nonE
USE 1
Pr i Pr i Pr i Pr i
USE 2
--- --- A2_d ---
USE 3
A1_d A1_d A1_d A1_d
diSP
1 1 1 1
Cloc
20 20 20 20
* Not applicable if a DC linear input is fitted. Requires internal jumper change.
