Secure APEX 100 User Manual

PICS
BGX501-742-R01, APEX 100 User Manual
Page 11 of 104
2.1.1 Front Cover Sealing
Front
Cover
Translucent
Transparent
Window
Locking Screw
& Sealing points
Right-hand side
Sealing & Locking point
Left-hand side
Sealing & Locking point
Figure 7: Front Cover Sealing Arrangement
The front cover can be sealed in the closed position. This will stop the front cover from being opened and
restrict unauthorised access to the MD pushbutton and internal areas. There are also sealing points on either
side of the meter for securing it to a rack or frame. The sealing bore diameter is 2.0 mm and is suitable for
Ferrule, NIC & SAFCON type seals.
