6.3 EMI/EMC specification
Radiated Emission
CISPR 22 (Class A equipment)
Conducted emission
CISPR 22 (Class A equipment)
Internal limits are 8 dB less than the CIPSR limits
Electro static discharge
IEC 61000-4-2
Contact Direct type: +/- 8KV
Contact Indirect type: +/- 8KV
Air discharge: +/- 15 KV
Internal limits
Contact Direct type: +/- 10KV
Contact Indirect type: +/- 10KV
Air discharge: +/- 18 KV
Radiated susceptibility
IEC 61000-4-3
Conducted susceptibility
IEC 61000-4-6
Electrical fast transients
IEC 61000-4-4
Internal limits
+/- 4KV for Aux ports
Damped oscillatory waves
IEC 61000-4-12
AC voltage test
CBIP 304, IS 14697
Surge & impulse
SP 1618 - +/- 12kV, 9 J
IEC 61000-4-5
+/- 10KV, 300 J (LT)
+/- 6KV, 300 J (HT)
Internal limits
+/- 10KV, 300 J
Immunity against magnetic
interference
CBIP 304 (0.27T) , IS14697 (0.27T)
