BGX501-742-R01, APEX 100 User Manual
Page 93 of 104
6.2 Metrological Specification
Meter type
3-phase 4-wire (HT4), 3-phase 3-wire (HT3),
3-phase 4-wire (LT) (Common Meter-Wall type) &
3-phase 4-wire (HT4), 3-phase 3-wire (HT3)
(Common Meter-Rack type)
Measuring elements
2/3(HT3/HT4/LT), HT3/HT4 field configurable
Current measuring element
CT
Voltage measuring element
Potential Divider
Class of accuracy
0.2s (Active & Reactive)
Reference voltage (field configurability
for different ratings)
69.3V/66.5/63.5V/57.7V(HT4),
120/115/110/100V(HT3), 230/240V(LT)
Operating voltage range
+30/-40% of V nominal for APS-Wall, APS-Rack &
Self power Rack meter.
+30/-30% of V nominal for Self power Rack meter.
And +30/-20% of V nominal for Self power Wall
meter.
Current range
1(10) 1000% Imax (field configurability will be
available for the 1-2Amp, 5-10Amp, 2.5-10Amp,
1-6Amp, 2-10A).
Meter constant
Two metrological pulse LED‟s configurable
through software
Frequency
45 to 65 Hz
Power Consumption in case of Aux
supply (with communication module)
Voltage circuit<0.5VA/phase
Current circuit<0.5VA/phase
Auxiliary APS<8VA
Power consumption in case of Self
power supply (with communication
module)
Voltage circuit<6VA/phase
Current circuit<0.5VA/phase.
