Secure APEX 100 User Manual

Page 16 of 104
BGX501-742-R01, APEX100 User Manual
PICS
A
S
e
a
l
i
n
g
P
o
i
n
t
s
R
e
a
r
C
o
n
n
e
c
t
o
r
C
o
v
e
r
DETAIL “A”
Enlarged View
of Sealing Points
S
e
a
l
i
n
g
P
o
i
n
t
s
Figure 13: Rear Sealing Points – Single Rack Example
Rear Cover
Sealing Points
Figure 14: Rear Sealing Points – 19” Rack, Two Meter Example
2.2.2 Pulse I/O
I/O Pulses (12)
4 Fixed Pulse
Inputs
24-40V DC
4 Configurable
Pulse Outputs
Pulse output rating:
110-230V AC/DC
@100mA.
Pulse input rating:
24-40VDC
4 Fixed Pulse
Outputs
110V-230V
AC/DC @100mA
Figure 15: Pulse I/O Variants
