2 Rack Mounted Product Description
2.1 Front Cover
Menu
User
Controls
LCD Graphic
Display
Calibration LEDs
(LED1 & LED2)
Pulse Outputs
Optical
1107 Port
Apex 100
1LED 1 LED 22 3 4
Pulse Output
Figure 4: Front View
The front cover is made of translucent plastic with a transparent window to view the display. The cover has two
top hinges which allow the complete front panel to swing-up, allowing access to the MD button. The battery
compartment and USB port are optional features. The cover is secured in position by a retaining screw and
sealed.

Secure APEX 100 Specifications

General

Brand	Secure
Model	APEX 100
Category	Measuring Instruments
Language	English
