BGX501-742-R01, APEX100 User Manual
Appendix B: Material Declaration
The material declaration for the meter and rack are shown below:
Enclosure Rack- Mild steel with Aluminium
Meter- Mild steel overall
Meter back plate- Mild steel
Meter current and voltage terminals- Brass with gold and silver plating
Handle – Mild steel
Screws- M3 for sealing meter with rack and M4 elsewhere
Front hinged plate – PC (Polycarbonate)
*Rack carries the female part of Essailec connector and meter carries the male part of essialic connector with all
the back side communication ports in the form of RJ45 connector.
