BGX501-742-R01, APEX100 User Manual
PICS
2.4.1 Apex 100 with 11” Rack Mounting Diagrams and Dimensions
The following diagrams show dimensional and sealing points for the Apex 100 when used with the 11” rack
57.10
132.50
261.80
279.60
C
L
C
L
243
376.25
293.30
50.30
R5
7.50
Figure 20: Front and Side View
