Secure APEX 100 User Manual

Page 14 of 104
BGX501-742-R01, APEX100 User Manual
PICS
Variant
Pulse
Outputs
Pulse Inputs
Configurable
*Pulse I/O
Status
Counter
A
4
1
-
-
B
4
4
-
-
C
4
2
2
-
D
4
4
-
4
E
4
2
-
4
* I/O information will be handled by the I/O type
Variant 1 is the default
Variants 2-5 are available on request
Table 1: Pulse I/O Variants
The diagram shows the rear connector with its pinning diagram for Variant A (not fully loaded).
RS232
Ethernet
RS485 IN
RS485 OUT
C
B A
04 03
02 01
4 23 1
6
8
9
7
5
1
3
4
2
0
6
8
9
7
5
1
3
4
2
0
Figure 11: Essailec Plug-in Connectors
