BGX501-742-R01, APEX100 User Manual
PICS
24
Instantaneous
Current THD - Phase 1
Min/Max/Instant/Avg
25
Instantaneous
Current THD - Phase 2
Min/Max/Instant/Avg
26
Instantaneous
Current THD - Phase 3
Min/Max/Instant/Avg
27
Instantaneous
All Phase Current THD
Min/Max/Instant/Avg
28
Instantaneous
Active Power - Phase 1
Min/Max/Instant/Avg
29
Instantaneous
Active Power - Phase 2
Min/Max/Instant/Avg
30
Instantaneous
Active Power - Phase 3
Min/Max/Instant/Avg
31
Instantaneous
Active Power - All phase
Min/Max/Instant/Avg
32
Instantaneous
Reactive Power - Phase 1
Min/Max/Instant/Avg
33
Instantaneous
Reactive Power - Phase 2
Min/Max/Instant/Avg
34
Instantaneous
Reactive Power - Phase 3
Min/Max/Instant/Avg
35
Instantaneous
Reactive Power - All Phase
Min/Max/Instant/Avg
36
Instantaneous
Apparant Power - Phase 1
Min/Max/Instant/Avg
37
Instantaneous
Apparant Power - Phase 2
Min/Max/Instant/Avg
38
Instantaneous
Apparant Power - Phase 3
Min/Max/Instant/Avg
39
Instantaneous
Apparant Power - All Phase
Min/Max/Instant/Avg
40
Energy
Active Import -Fundamental (Q1+Q4)
Avg Consumption
41
Energy
Active Export Fundamental (Q2+Q3)
Avg Consumption
42
Energy
Active Import Total (Q1+Q4)
Avg Consumption
43
Energy
Active Export Total (Q2+Q3)
Avg Consumption
44
Energy
kVArh(I) while kWh(I) – Q1
Avg Consumption
45
Energy
kVArh(I) while kWh(E) – Q2
Avg Consumption
46
Energy
kVArh(E) while kWh(E) -Q3
Avg Consumption
47
Energy
kVArh(E) while kWh(I) – Q4
Avg Consumption
48
Energy
KVAH Import
Avg Consumption
