BGX501-742-R01, APEX 100 User Manual
Page 81 of 104
Instantaneous profile reading
Midnight energy profile reading
Load survey profile reading
Log wise events and transactions profile reading
A list of parameters and their OBIS code are shown below in the table.
Section
S.no
Group
Parameter
Independent
Parameters
1
Instantaneous
Real Time Clock – Date and Time
2
Instantaneous
R Phase Line Current – L
R
3
Instantaneous
Y Phase Line Current – L
Y
4
Instantaneous
B Phase Line Current – L
B
5
Instantaneous
Voltage – V
RN
for 3 Ф / 4W
6
Instantaneous
Voltage – V
YN
for 3 Ф / 4W
7
Instantaneous
Voltage – V
BN
for 3 Ф / 4W
8
Instantaneous
Voltage – V
RY
for 3 Ф / 3W
9
Instantaneous
Voltage – V
BY
for 3 Ф / 3W
10
Instantaneous
Signed Power Factor – R phase
11
Instantaneous
Signed Power Factor – Y phase
12
Instantaneous
Signed Power Factor – B phase
13
Instantaneous
Three Phase Power Factor – PF
14
Instantaneous
Frequency
15
Instantaneous
Apparent Power – kVA
16
Instantaneous
Signed Active Power – kW (+ import: - export)
17
Instantaneous
Signed Active Power – kW (+ import: - export)
18
Energy
Cumulative Energy – kWh (Import)
19
Energy
Cumulative Energy – kWh (Export)
20
Energy
Cumulative Energy – kVAh(Import)
