Secure APEX 100 User Manual

Page 84 of 104
BGX501-742-R01, APEX100 User Manual
PICS
Section
S.no
Group
Parameter
Instantaneous
Profile
50
Instantaneous
Real Time Clock – Date and Time
51
Instantaneous
R Phase Line Current – L
R
52
Instantaneous
Y Phase Line Current – L
Y
53
Instantaneous
B Phase Line Current – L
B
54
Instantaneous
Voltage – V
RN
for 3 Ф / 4W
55
Instantaneous
Voltage – V
YN
for 3 Ф / 4W
56
Instantaneous
Voltage – V
BN
for 3 Ф / 4W
57
Instantaneous
Voltage – V
RY
for 3 Ф / 3W
58
Instantaneous
Voltage – V
BY
for 3 Ф / 3W
59
Instantaneous
Signed Power Factor – R phase
60
Instantaneous
Signed Power Factor – Y phase
61
Instantaneous
Signed Power Factor – B phase
62
Instantaneous
Three Phase Power Factor – PF
63
Instantaneous
Frequency
64
Instantaneous
Apparent Power – kVA
65
Instantaneous
Signed Active Power – kW (+ import: - export)
66
Instantaneous
Signed Active Power – kW (+ import: - export)
67
Energy
Cumulative Energy – kWh (Import)
68
Energy
Cumulative Energy – kWh (Export)
69
Energy
Cumulative Energy – kVAh(Import)
70
Energy
Cumulative Energy – kVAh(Export)
71
Event
Number of power-failures.
72
Event
Cumulative power-failure duration
73
Event
Cumulative Tamper Count
