• To install this product, the entrance must be at least 1.45m (57.1in) in width
and 2.1m (82.6in) in height (without Assy Billboard) and 2.45m (96.4in) (with
Assy Billboard). If the entrance is too narrow, do not tilt the product carelessly.
If all the product weight is put on the casters at one side only, there could be
damage or deformation, causing serious accidents such as workers getting
caught underneath.
To install this product, the entrance must be at least 1.45m (57.1in) in width
and 2.1m (82.6in) in height (without Assy Billboard) and 2.45m (96.4in) (with
Assy Billboard).
Do not attempt to push/pull whilst holding onto the Assy Billboard. This may
result in part damage and/or personal injury.
2.07m (81.49 in)
0.25m (9.8 in)
0.6m (23.6 in)
0.25m (9.8 in)
OPERATION AREA (42inch Cabinet)
1.94m (76.3inches)
1.91m (75.1inches)
To Next Page
