To install this product, the entrance must be at least 1.8m (70.8in) in width
and 2.37m (93.3in) in height (without Assy Billboard) and 2.75m (108.2in)
in height (with Assy Billboard). If the entrance is too narrow, do not tilt the
product carelessly. If all the product weight is put on the casters at one side
only, there could be damage or deformation, causing serious accidents such
as workers getting caught underneath.
Do not attempt to push/pull whilst holding onto the Assy Billboard. This may
result in part damage and/or personal injury.
2.07m (81.49 in)
0.25m (9.8 in)
0.6m (23.6 in)
0.25m (9.8 in)
OPERATION AREA (55inch Cabinet)
2.28m (89.7inches)
1.93m (75.9inches)
To Next Page
