Sensitron PL4 +D - 2. Installation and Setup; 2.1 Unit Assembly, Layout, and Identification

ENGLISH
Pag. 30
2. Installation
2.1 Assembly and connections
Mount the gas control unit on DIN plank.
Figure 3) Gas control unit and its box (optional)
Connect the cable for power supply (24 Vdc) to the terminal block of gas control unit (see
gure below).
Figure 4) Power connection
- +
