DEC HEX DEC HEX DEC HEX DEC HEX DEC HEX DEC HEX DEC HEX
21 15 58 3A 95 5F 132 84 169 A9 206 CE 243 F3
22 16 59 3B 96 60 133 85 170 AA 207 CF 244 F4
23 17 60 3C 97 61 134 86 171 AB 208 D0 245 F5
24 18 61 3D 98 62 135 87 172 AC 209 D1 246 F6
25 19 62 3E 99 63 136 88 173 AD 210 D2 247 F7
26 1A 63 3F 100 64 137 89 174 AE 211 D3 248 (*) F8
27 1B 64 40 101 65 138 8A 175 AF 212 D4 249 (*) F9
28 1C 65 41 102 66 139 8B 176 B0 213 D5 250 (*) FA
29 1D 66 42 103 67 140 8C 177 B1 214 D6 251 (*) FB
30 1E 67 43 104 68 141 8D 178 B2 215 D7 252 (*) FC
31 1F 68 44 105 69 142 8E 179 B3 216 D8 253 (*) FD
32 20 69 45 106 6A 143 8F 180 B4 217 D9 254 (*) FE
33 21 70 46 107 6B 144 90 181 B5 218 DA 255 (**) FF
34 22 71 47 108 6C 145 91 182 B6 219 DB
35 23 72 48 109 6D 146 92 183 B7 220 DC
36 24 73 49 110 6E 147 93 184 B8 221 DD
37 25 74 4A 111 6F 148 94 185 B9 222 DE
2.13 Programming from a PC
The PL4 +D gas control unit is fully programmable from a personal computer by means of
special software. The software has been designed for simple and fast programming. Con-
nection to the PC takes place via the USB port, available on the main board of the gas control
unit.
The following cable is to be used:
Figure 18) USB CABLE (printer type)
