Sensitron PL4 +D - Page 45

ENGLISH
Pag. 39
Figure 13) Detector connection by STG/IN8S
d
+
A
B
From the control panel or from the remote auxiliary power supply
Twisted / shielded 2x0,2 cable (Belden 9841 or equivalent)
-V I8 I7 I6 I5 +V -V I4 I3 I2 I1 +V
-V B A +V
REMOTE INPUT
MODULE STG/IN8S
-
+ s -
4-20mA
GAS DETECTOR
(up to 8)
STG/IN8S
MODULE
Control panel unit
