3.2.8 Display/LED’s
Check indicator LED’s and the display for defects:
1. Connect the SDM to AC power. Switch the SDM OFF and ON again: During the
POST, the Alarm Mute Indicator (yellow LED) and the ON/OFF Indicator (green
LED) are activated. The AC Power/Battery Indicator LED is lit yellow (battery
charging) or green (battery full). Refer to
Figure 1 Front Panel of the SDM
for location of the indicator LED’s.
2. Control the readability of the following critical areas: graph window, numerical
displays, status bar may be accepted.
If the above described functions do not operate properly contact your local SenTec
representative or send back the monitor according to
section 8.6 "Instructions for
Shipment”.
For SenTec authorized service technicians only: If the above requirements
for the LEDs are not fulfilled then replace the SDM Case, upper part according to the
Repair Manual for the SDMS
(HB-005755).
If the above requirements for the display are not fulfilled then replace the display
according the
Repair Manual for the SDMS
(HB-005755).
