Take 5 User’s Guide
Arpeggiator
Arpeggiator Parameters
Arpeggiator On/Off: This button turns the Arpeggiator on and off.
Arp Mode: Sets the order in which notes play when the Arpeggiator is on. The
setting appears in the lower left of the display. See the table below.
Arp Mode Behavior
Up Plays from lowest to highest note
Down Plays from highest to lowest note
Up + Down Plays from lowest to highest and back to lowest
Random Plays notes in random order
Assign Plays notes in the order the keys were pressed
Octave: 1, 2, 3—
Set to 1, only the held notes are arpeggiated. Set to 2,
the held notes and the notes one octave above them arpeggiate. Set to 3,
the held notes and the notes one and two octaves above them arpeggiate.
Repeat: 1, 2, 3 —Set to off, each note in the arpeggio plays once. Set to
1, each note in the arpeggio plays twice. Set to 2, each note in the arpeg-
gio plays three times. Set to 3, each note in the arpeggio plays four times.
Relatch (in the Program Menu): Off, On—Works in conjunction with
hold. When hold and the Arpeggiator are on, and arp relatch is off,
played notes are held on and arpeggiated, with additional played notes
added to the held notes and the arpeggio. When arp relatch is on, played
notes are held on and arpeggiated, but additional played notes will restart
the arpeggio with the new notes. If you release all keys and play new
notes, the arpeggio restarts using the new notes.
